Android media player boxes customized design with Android 5.0/7.1/8.0/9.1 OS Ram 2G 4G ROM 8G 16G 32G FOR OPTION
Shenzhen TOPADKIOSK is highly specialized in the field of LCD Digital Signage products, LCD DISPLAY, QLED display, OLED display. We have developed our own LCD products Series, such as digital signage, all In One PC, touch screen, lcd video wall, outdoor IP67 High Brightness LCD Digital Signage and TV, etc, the size is available with 7" Inch to 98 Inch etc. These products have been widely used in the USA, Europe, Southeast Asia, the Middle East, Africa and other countries and regions. These products are suitable for advertising in lots of areas, such as buildings, shops, hotels, supermarkets, railway stations, bus stations, airports, taxis, buses and other outdoor areas. Quality and Service is Our Symbol.The most important factor for us to win our customers' hearts and found the long-term business relationships with our customers is quality and service. With these years' research, development and manufacture, we have accumulated our special experience and methods to control the quality through the whole process of designing, material purchasing, manufacturing and marketing. Especially for the material quality, we have founded firm relationships with our suppliers and even invested in some supply companies to directly control quality. We offer 7*24 hours service to all our clients. Our sales person and after-selfteam will keep on line to answer and solve all questions for you. Providing services beyond our customers' expectations is our purpose. Our excellent pre-sales services and after-sales services have earned us many customers' hearts. Customized designs are most welcome! Our advantage is to give solution to our clients according to their needs.
Mini PC i3 I5 I7 SSD HDD Quad Core Computer For Home Office WIFI Fanless Desktop Computer AND KIOSK
High quality MINI PC and Android player with I3 I5 I7 CPU for kiosk lcd display digital signage advertising player
MINI PC with customized designed function and shape for lcd digital sigange advertising player screen kiosk
① Power adapter:
We have multiple specifications of power supplies, which are selected by default based on your shipping address.If you have special demands, please contact us in time.
EU,UK,US,AU,Brazil,etc.
② Payment:
We are supporting L/C; DA; DP; T/T; Western Union; Alibaba and negotiation.
③ Shipping Methods:
Shipping by DHL, FedEx, UPS, Aramex, post and Alibaba, and negotiation. ( choose as you prefer)
1,How about the waranty?
A:The first year we provide free repair service, the second year and the third year, free repair but we will charge for the parts that need to change.
2,Can i print my logo on your mini pc?
A:Yes,please provide your logo file, and we will confirm the design effect to you before production.we also doing OEMODM.
3,What is the MOQ?
A:We can sell one sample for your test.
4,How long the package will ready after I buy the mini pc?
A: It takes about three days for inspection and assembly. Generally, 10 units can be shipped in about 3 days, and 50 units can be shipped in about 8 days. More information please kindly check with us.
5,Are your mini pc in stock?
A:Yes, most of our models are in stock. You can confirm the inventory with us before placing your order.
MINI PC with customized designed function and shape for lcd digital sigange advertising player screen kiosk
- Products Status:
-
New, Stock
- Warranty(Year):
-
1-Year
- Certification:
-
ce, Sgs
- Hard Drive Capacity:
-
≤ 40GB, 60GB, None, 120GB, 500GB, 1TB, 256GB
- Use:
-
For Home and Student
- Plugs Type:
-
US, JP, CN, AU, UK, EU
- Hard Drive Type:
-
SSD+HDD
- Operating System:
-
No, Win7/Win8/10 Linux
- Processor Type:
-
In tel Co re
- Graphics Card Chipset:
-
Integrated Card
- HDD Rotation Speed:
-
SSD
- Processor Series:
-
In tel Co re I3
- Video Memory:
-
2 GB
- Video Card:
-
In tel H D graphics
- After-sales Service:
-
Repair
- Keywords:
-
Fanless desktop computer
- CPU:
-
In tel Co re i3-4010Y/4010U Processor 3M Cache, 1.30/1.7 GHz
- Graphics Card:
-
In tel H D Graphics 4200/4400
- Memory:
-
1 x DDR3L (1.35V Low voltage)
- Storage:
-
1*mSATA+1*2.5 Inch SATA HDD
- WIFI:
-
802.11b/g/n
- Interface:
-
6x USB/ VGA/ HD/ LAN/MIC/SPK
- Dimension:
-
136x 126x 40cm
| Packaging Information : |
| Dimension | 26 x20 x10cm | 26 x 20x 20 cm | 42x 25x 20cm | 45x 25x 38cm | | |
| Quantity | 1unit | 2 units | 5units | 10units | | |
| Weight | 1.5KG | 3KG | 7.5KG | 15KG | | |
| Packing list: |
| Mini PC | User manual | VESE mount | WIFI Anttenna | Power cable
sata cable | hard disk mounting bracket | Power adapter |
| 1 | 1 | / | / | / | / | 1 |
| Processor |
| CPU | 1.Intel Core i3-4010Y Processor 3M Cache, 1.30 GHz 2.Intel Core i3-4010U Processor 3M Cache, 1.70 GHz |
| BIOS | American |
| Memory |
| Technology | DDR3L-1600/1333 MHz |
| Max Capacity | Up to 8GB |
| Socket | 1x 204-pin SOSIMM |
| Display |
| Graphic Engine | Intel HD Graphics 4200/4400 |
| HD | Maximum support resolution 1920×1080@60Hz |
| Ethernet |
| LAN | 10/100/1000/ Mbps Realtek 8111F,Support network wake up |
| Audio |
| Chipset | Apply Realtek ALC662Audio control chip, support for two channels, stereo,Line out |
| Expansion |
| Mini PCIe | 1 x Half size Mini-PCIe( For WIFI) |
| Storage |
| mSATA | 1 x Full size mini PCIe slot( For SSD) |
| Other |
| Watchdog Timer | Support |
| Front I/O Interface |
| USB2.0 | 4 |
| USB3.0 | 2 |
| I/O |
| RJ-45 | 1 |
| HD | 1 |
| Audio | Line-in, Line-out |
| Miscellaneous |
| LED Indicators | Power |
| Control | Power Switch |
| Power |
| Power Type | AT |
| Input Voltage | 12V |
| Connector Type | 2-Pole Phoenix DC plug in |
| Environment |
| Operational Temperature | 0 ~70℃ |
| Non-Operational Temperature | -20℃ ~ 85℃ |
| Relative Humidity | 5%-95%Relative humidity, no condensation |
| Physical |
| Mounting | Desk/ Wall Mount |
| Dimension(W x H x D) | System dimension: 136x 126x 40mm |
| Weight | 1.3KG |
|
|
|
